Overview
Heavy-duty commercial air-cooled V-twin for commercial mowers and industrial equipment. Available with a heavy-duty shift-type starter (recoil option) and heavy-duty air filtration.
Specifications
| Series | FX Heavy Commercial V-Twin |
|---|---|
| Displacement (cc) | 603 |
| Net Power (hp) | 16.5 @ 3600 rpm |
| Max Torque (ft-lbs) | 32.2 @ 2000 rpm |
| Bore x Stroke (in) | 2.9 x 2.8 |
| Bore x Stroke (mm) | 73 x 72 |
| Compression Ratio | 8.1:1 |
| Oil Capacity w/ filter (qt) | 1.8 |
| Cylinders | 2 |
| Starting System | Electric (heavy-duty shift-type starter); recoil option |
| Shaft Type | Vertical |
| Dry Weight (lb) | 89.7 |
You May Also Like
Engines
Briggs & Stratton Vanguard 36.0 Gross HP (Big Block V-Twin)
