Commercial Attachments
Features
Key Features
- Smooth, solid power
- Stability and traction
- The long and short of it
- Cutting-edge design
- Ease of maintenance
- Take no prisoners
- Strong bones
- Heavy-duty construction
- Ogura PTO Clutch Brake
Specifications
| Total Fuel Capacity | 3.5 gallons |
|---|---|
| Drive Tires | 20 in x 8 in-8 in (42") 20 in x 10 in-8 in (52") 20 in x 10 in-8 in (61") |
| Caster Tires | 11 in x 6 in-5 in |
| Drive System Type | Hydro-Gear ZT2200 (EZT) |
| Internal Pumps | 10cc |
| Internal Motor | 10cc |
| Forward Ground Speed | 7 mph |
| Reverse Ground Speed | 5 mph |
| Parking Brake | Hand lever |
| Cutting Widths | 42 in, 52 in and 61 in |
| Type | Heavy-Duty Hero Cutter Deck |
| Cutting Height | 1.5 in to 4.5 in in .25 in increments |
| Lift | Foot-operated pedal |
| Construction | Dual-plate cutter deck constructed of 2 steel plates. Reinforcement plate at cutter deck spindles. |
| Spindles | Aluminum housing with sealed ball bearings. |
| Blade Engagement | Ogura GT1 (74 ft lb) - (42 in) Ogura GT1 (74 ft lb) - (52 in) Ogura GT2 (108 ft lb) - (61") Adjustable air-gap for extended life. |
Models & Configurations
| Model | Deck | Engine | HP |
|---|---|---|---|
| SLS-42H-20PX | 42 in | Briggs & Stratton® PXi Series | 20 |
| SLS-52H-22PX | 52 in | Briggs & Stratton® PXi Series | 22 |
| SLS-52H-24PX | 52 in | Briggs & Stratton® PXi Series | 24 |
| SLS-61H-24PX | 61 in | Briggs & Stratton® PXi Series | 24 |
Dimensions
| 42 in SLS | 52 in SLS | 61 in SLS | |
|---|---|---|---|
| Length | 67.5 in | 67.5 in | 73.5 in |
| Width (chute down) | 54.5 in | 64.5 in | 73.5 in |
| Width (chute in transport position) | 43 in | 53 in | 62 in |
| Height | 39 in | 39 in | 39 in |
