Features
Key Features
- Integrated Parking Brake: Activated through the hand controls. It's simple, and intuitive so you can get to work faster.
- Hydro-Gear ZT3400 Transaxles: The short axle design reduces bearing load for longer life. Sealed venting system prevents leaks and simplifies maintenance.
- Premium Suspension Seat: Fully adjustable with additional spring isolators underneath for even more comfort.
- 52" & 61" Aero Core Deck: Handle a wide range of cutting conditions delivering a professional cut quality.
- Light Up Your Cut: Standard front headlight with optional dual corner-pod lights.
- 24" Rear Drive Tires: Oversized rear tires provide improved traction and lower ground pressure for a smoother ride.
- Large Capacity Fuel Tank: 7.5-gal capacity positioned to improve line of sight to edge of cutter deck.
- Integrated Front and Rear Tie-Down: Durable tie-downs for secure and easy transport between jobs.
- Simplified Electrical System: Single relay, single fuse design keeps electrical diagnosis easy.
- Durable Height-of-Cut Selector: Vertical oriented design is easy to reach. 1.5 to 5 inch range.
- Oversized Deck Pulleys: Larger radius pulleys reduce belt flex for improved belt life.
- Underbody Protection: Engine and hydraulic component protective plates keep critical components safe.
- Rugged Deck Belt Setup: Compression spring and dual belt design reduces wear and maximizes belt life.
- Operator Comforts: Ease to reach operator station with 12volt accessory for charging devices and cell phone seat pocket.
- Sealed Caster Bearings: ZERO grease zerks on the entire machine = more time mowing.
Overview
COMFORTABLE. EFFICIENT. LOW-MAINTENANCE. The Wright ZTS is the perfect entry into Wright’s mid-mount zero-turn mower lineup, designed for commercial cutters who want standout comfort without sacrificing durability or performance. Every detail is built for the real-world needs of landscapers, blending the ease of a ride-on with the efficiency and reliability Wright is known for. Take on demanding jobs with less downtime and more return on investment. Whether you’re expanding your fleet or upgrading your lineup, the ZTS delivers a smoother ride, faster operation and proven productivity that pays off day after day.
Specifications
| Deck Size | 52 in / 61 in |
|---|---|
| Engine | Kawasaki FT730V |
| Horsepower | 24 HP |
| Blade Length | 18 in / 21 in |
| Blade Quantity | 3 |
| Deck Type | Floating-side discharge |
| Deck Lift System | Quick-Cut |
| Cut Height (min) | 1.5 in |
| Cut Height (max) | 5 in |
| Deck Steel Gauge | 7 Gauge |
| Spindle Type | Ductile Iron |
| Deck Configuration | Aero Core |
| Start Type | Electric |
| Fuel Capacity | 7.5 gal |
| Forward Speed | 10.0 mph |
| Reverse Speed | 4.5 mph |
| Max Acres Per Hour | 5.25 / 6.16 |
| Drive System | Hydro |
| Transaxle | Hydro-Gear ZT3400 |
| Operator Controls | Over the lap controls |
| Hour Meter | Digital |
| Class | Heavy-duty |
| Generation | Gen 1 |
| Caster Tire Type | Pneumatic |
| Caster Tire Diameter | 13.00 in |
| Caster Tire Width | 6.50 in |
| Caster Rim Diameter | 6.00 in |
| Drive Tire Diameter | 24.00 in |
| Drive Tire Width | 9.50 in / 12.00 in |
| Drive Tire Ply | 4 ply |
| Drive Rim Diameter | 12.00 in |
Models & Configurations
| Model | Deck | Engine | HP |
|---|---|---|---|
| WZTS52SFT7301B | 52 in | Kawasaki FT730V | 24 HP |
| WZTS61SFT7301B | 61 in | Kawasaki FT730V | 24 HP |
Dimensions
| 52 in | 61 in | |
|---|---|---|
| Length | 84.00 in | 83.00 in |
| Width (deflector down) | 64.50 in | 73.50 in |
| Width (deflector up) | 52.00 in | 61.00 in |
| Weight | 1160 lb | 1210 lb |
